Specification
Power supply230Vac, 50Hz (IEC)
FuseF5A, 250V
Output power rms @ 4 Ohms4 x 200W
Output power rms @ 8 Ohms4 x 100W
Amplifier : constructionClass D
Frequency response20Hz - 20kHz ±0.5dB
Microphone inputs2 x 6.3mm jack (mono)
Line inputsLine 1: L+R (6.3mm jack/RCA), Line 2: L+R (RCA)
Input sensitivity : line0.775Vrms
Auxiliary input3.5mm stereo jack
Input sensitivity : aux0.480Vrms
Input impedance20k Ohms (balanced), 10k Ohms (unbalanced)
Audio sourceUSB/SD mp3 playback, FM tuner, BT receiver
Bluetooth version2.3
Input controlsAux, Media, Line1, Line2, Mic1, Mic2, Talkover
Line output4 x RCA
Speaker outputs4mm binding posts (4 channels)
Antenna connectionF type (FM tuner)
Output controls2 x source select, 2 xBass, 2 xTreble, Ch1, Ch2, Ch3, Ch4
Dynamic range92dB
THD +N<0.1%
ProtectionThermal, over-current, over-voltage, short-circuit
Dimensions482 x 240 x 88mm
Weight5.98kg
